Authorised Victron Energy InstallerVictron Energy Phoenix Inverter 48/250 230V VE.Direct SCHUKO PIN481251200
Victron EnergyExcellent on Google

Victron Energy Phoenix Inverter 48/250 230V VE.Direct SCHUKO PIN481251200

Victron part no. PIN481251200

£81.99Available to order, usually dispatched in 6 to 10 working days
Usually dispatched in 6 to 10 working daysUK delivery, priced at checkout
5 years standard warrantyVictron Energy warrants its products to be free from defects in workmanship and materials for a period of 5 years from the date of purchase by the original end-user. Victron warranty policy
14-day returnsOn unused standard items
Tom Alderdice
Not sure it's the right size?Free 30-minute call with Tom, or ring 01539 761 467.
Book a call
Overview

About this product

The Victron Phoenix Inverter 48/250 230V VE.Direct SCHUKO is an efficient and reliable solution for powering 230V AC devices from 48V DC batteries. Ideal for off-grid applications, mobile homes, and backup power solutions, it features high start-up power to support devices like electric tools and lamps. The VE.Direct communication port enables easy configuration and monitoring through the VictronConnect app, while the ECO mode reduces energy consumption by putting the inverter into standby when the load falls below 15W. With its robust design and 5-year warranty, this inverter is built for long-lasting performance.

Key Features

Features

VE.Direct communication port

The VE.Direct port can be connected to:

  • A computer (VE.Direct to USB interface cable needed)
  • Apple and Android smartphones, tablets, MacBook’s and other devices (VE.Direct Bluetooth Smart dongle needed)

Fully configurable:

  • Low battery voltage alarm trip and reset levels
  • Low battery voltage cut-off and restart levels
  • Dynamic cut-off: load dependent cut-off level
  • Output voltage 210 to 245V
  • Frequency 50 Hz or 60 Hz
  • ECO mode on/off and ECO mode sense level

Monitoring:

  • In- and output voltage, % load and alarms

Proven reliability

The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature.

High start-up power

Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.

ECO mode

When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.

Remote on/off

A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector.

DC connection with screw terminals

No special tools needed for installation.

Specifications

  • Brand: Victron Energy
  • Manufacturer Part No.: PIN481251200
  • Output Power: 250VA (Peak 400W)
  • Nominal Voltage: 48V DC
  • Output Voltage: 210 to 245V
  • Efficiency: 88%
  • Plug Type: SCHUKO (European)
  • Warranty: 5 Years
  • IP Rating: IP21
  • Dimensions: H86 x W165 x D260 mm
  • Weight: 2.4 kg

Datasheets

Datasheet

Product Manual
