Overview

About this product

The Victron Battery Management System (BMS) 12/200 is an advanced, compact solution designed to safeguard your LiFePO4 Smart Batteries while managing 12V systems with 12V alternators. Perfectly suited for applications in vehicles and boats, this system offers robust protection for each individual battery cell.

The BMS 12/200 monitors vital battery parameters and will automatically disconnect the alternator, charge sources, or DC loads if the system detects low battery voltage, high battery voltage, or over temperature conditions. This ensures optimal battery health and prevents damage. Its dedicated alternator connection provides current limiting and allows safe one-way traffic from the alternator to the battery, protecting your starter battery from excessive discharge.

Equipped with a remote on/off connector, the system can be easily turned on or off via a remote switch, offering added convenience and control. The BMS 12/200 is an essential addition to any system where battery longevity and safety are priorities.

Key Features

  • All-in-One Solution: Combines Battery Management System, Current Limiter, Battery Combiner, and Battery Protector.
  • Ideal for 12V Systems: Perfect for vehicles, boats, and other 12V applications.
  • Cell Monitoring: Continuously monitors and protects each battery cell.
  • Disconnection Protection: Automatically disconnects alternator, charge sources, or DC loads in case of low/high voltage or over temperature.
  • Dedicated Alternator Connection: For current limiting and one-way traffic from the alternator to the battery.
  • Starter Battery Protection: Safeguards against excessive discharge of the starter battery.
  • Remote On/Off Control: Convenient remote on/off connector for easy system control.

Specifications

  • Brand: Victron Energy
  • Manufacturer Part Number: BMS012201000
  • GTIN: 8719076021025
  • Warranty: 5 Years
  • Country of Manufacture: India
  • System Compatibility: 12V systems with 12V alternators
  • Functionality: Battery Management, Current Limiting, Battery Combiner, Battery Protector
  • Remote Control: Remote On/Off Connector
  • Protection Features: Low/high voltage and over temperature protection
  • Battery Type Compatibility: LiFePO4 Smart Batteries
